| Quantity: | |
|---|---|
CB3-260
Changbo
84223030
▼Main performance and features
☀The equipment realizes automatic packaging, automatic material conveying, automatic measurement, automatic bag feeding and automatic sealing.
☀The whole process is mechanized, only one person is responsible for cutting the material to complete the operation, and it can also be connected to the production line to achieve fully automatic production.
☀The measurement accuracy is high, it can work continuously, save a lot of labor packaging costs, and pay back the cost quickly.
☀The whole set of equipment is controlled by linkage, automatically controls the feeding, no packaging without material, no waste.
☀High-speed automatic, easy to operate, permanent maintenance service, low maintenance cost.
☀This machine uses prefabricated bags with perfect sealing and low loss of packaging materials
☀ Quickly change the bag specifications, and the bag width can be adjusted automatically with one button
☀The machine cost is low and the return is fast.
型号(Model) | CB3-260 |
包装材料 (Packing material) | 三边封袋、四边封袋、自立袋、手提袋、壶口袋、拉链袋、复合袋等等 3-side, four edge-sealing bag, self-reliance bag, handbag, spout bags, zipper bag, compound bag, etc |
包装尺寸 (Packing size) | 宽(W)60-250mm 长(H)100-300mm |
充填范围 (Filling range) | 10-1000g |
包装速度 (Packing speed) | 15-20包/分（其速度由产品自身充填量决定） 15-20 bpm(speed depends on filling product character) |
计量平均精度 (Filling precision) | ≤±1 |
总功率 (Total power) | 3.5KW |
外形尺寸 (Outer dimension) | L:1800mm*W:850mm*H:1250mm（长X宽X高） |
适用范围 (Application) | 1. 块状物料类：豆腐干、鱼仔、鸡蛋、糖果、红枣、麦片、巧克力、饼干、花生等 Block material: bean curd cake, fish, eggs, candy, red jujube, cereal, chocolate, biscuit, peanut, etc |
2. 颗粒类：结晶味精、颗粒状药物、胶囊、种子、化学原料、砂糖、鸡精、瓜子、果仁、农药、肥料、饲料等 Granular type: crystal monosodium glutamate, granular drug, capsule, seeds, chemicals, sugar, chicken essence, melon seeds, nut, pesticide, fertilizer | |
3. 粉剂类：奶粉、味精、调味剂、洗衣粉、葡萄糖、化学原料、精细白糖、农药、肥料等 Powder type: milk powder, glucose, monosodium glutamate, seasoning, washing powder, chemical materials, fine white sugar, pesticide, fertilizer, etc | |
4. 液体/酱体类：洗涤剂、黄酒、酱油、米醋、果汁、饮料、番茄酱、花生酱、果酱、辣椒酱、豆瓣酱等 Liquid/paste type: detergent, rice wine, soy sauce, rice vinegar, fruit juice, beverage, tomato sauce, peanut butter, jam, chili sauce, bean paste | |
5. 酱腌菜：雪菜、泡菜。酸菜、萝卜菜 Class of pickles, pickled cabbage, kimchi, pickled cabbage, radish, etc | |
6. 其他可装袋物料 Other bagging materials | |
主要标准配件 (Main components) | 1. 打码机2.PLC控制系统3.开袋装置4.震动装置5.气缸6.电子阀7.温控仪8.真空泵9.变频器10.输出系统 1. Code printer 2. PLC control system 3.Bag opening device 4. Vibration device 5.Cylinder 6. Electromagnetic valve 7. Temperature controller 8.Vacuum pump 9. Inverter 10. Output system |
▼Main performance and features
☀The equipment realizes automatic packaging, automatic material conveying, automatic measurement, automatic bag feeding and automatic sealing.
☀The whole process is mechanized, only one person is responsible for cutting the material to complete the operation, and it can also be connected to the production line to achieve fully automatic production.
☀The measurement accuracy is high, it can work continuously, save a lot of labor packaging costs, and pay back the cost quickly.
☀The whole set of equipment is controlled by linkage, automatically controls the feeding, no packaging without material, no waste.
☀High-speed automatic, easy to operate, permanent maintenance service, low maintenance cost.
☀This machine uses prefabricated bags with perfect sealing and low loss of packaging materials
☀ Quickly change the bag specifications, and the bag width can be adjusted automatically with one button
☀The machine cost is low and the return is fast.
型号(Model) | CB3-260 |
包装材料 (Packing material) | 三边封袋、四边封袋、自立袋、手提袋、壶口袋、拉链袋、复合袋等等 3-side, four edge-sealing bag, self-reliance bag, handbag, spout bags, zipper bag, compound bag, etc |
包装尺寸 (Packing size) | 宽(W)60-250mm 长(H)100-300mm |
充填范围 (Filling range) | 10-1000g |
包装速度 (Packing speed) | 15-20包/分（其速度由产品自身充填量决定） 15-20 bpm(speed depends on filling product character) |
计量平均精度 (Filling precision) | ≤±1 |
总功率 (Total power) | 3.5KW |
外形尺寸 (Outer dimension) | L:1800mm*W:850mm*H:1250mm（长X宽X高） |
适用范围 (Application) | 1. 块状物料类：豆腐干、鱼仔、鸡蛋、糖果、红枣、麦片、巧克力、饼干、花生等 Block material: bean curd cake, fish, eggs, candy, red jujube, cereal, chocolate, biscuit, peanut, etc |
2. 颗粒类：结晶味精、颗粒状药物、胶囊、种子、化学原料、砂糖、鸡精、瓜子、果仁、农药、肥料、饲料等 Granular type: crystal monosodium glutamate, granular drug, capsule, seeds, chemicals, sugar, chicken essence, melon seeds, nut, pesticide, fertilizer | |
3. 粉剂类：奶粉、味精、调味剂、洗衣粉、葡萄糖、化学原料、精细白糖、农药、肥料等 Powder type: milk powder, glucose, monosodium glutamate, seasoning, washing powder, chemical materials, fine white sugar, pesticide, fertilizer, etc | |
4. 液体/酱体类：洗涤剂、黄酒、酱油、米醋、果汁、饮料、番茄酱、花生酱、果酱、辣椒酱、豆瓣酱等 Liquid/paste type: detergent, rice wine, soy sauce, rice vinegar, fruit juice, beverage, tomato sauce, peanut butter, jam, chili sauce, bean paste | |
5. 酱腌菜：雪菜、泡菜。酸菜、萝卜菜 Class of pickles, pickled cabbage, kimchi, pickled cabbage, radish, etc | |
6. 其他可装袋物料 Other bagging materials | |
主要标准配件 (Main components) | 1. 打码机2.PLC控制系统3.开袋装置4.震动装置5.气缸6.电子阀7.温控仪8.真空泵9.变频器10.输出系统 1. Code printer 2. PLC control system 3.Bag opening device 4. Vibration device 5.Cylinder 6. Electromagnetic valve 7. Temperature controller 8.Vacuum pump 9. Inverter 10. Output system |
