The following spout pouches can be filled:
Introduction of 5000 pouches/h Automatic stand up pouch juice filling capping machine:
1. Model CB-5000 is 5000 pouches/h Automatic stand up pouch juice filling capping machine.
2.It can packing any liquid such as juice yogurt, water, jelly, soymilk, cooking oil, liquid soap etc. Also used for the semi fluid,example tomato sauce,honey,fruit pasteJam etc.
3. Fully automatic pouch supply, filling, cap supply, cap sorting, capping.
4. It with five nozzles max packing speed 5000bags/hour.
5. International spare parts brand.
Specification of 5000 pouches/h Automatic stand up pouch juice filling capping machine:
1> CB-5000 5000 pouches/h Automatic stand up pouch juice filling capping machine is used for any liquid’s automatic bags supplying,filling and capping,such as juice,milk，jam,yogurt,seasonings,food industry and medicine,daily chemical,pesticide ant other industries.
2> Full function,rational structure,easy operation and maintenance.It conforms to food hygiene standard.This machine combines machine,electricity and air.Electric and pneumatic components adopt imported devices,reliable performance,long service life,convenient repair,and install leakage protection,protect personal safety.
3> standing spout pouch packing machine can do automatic pouch sending, rationed filling,spout cleaning,
cap tidy and cover,cap screwing,end product discharging.
4> The Spout Bag Filling Capping machine has 5 filling nozzles,and hot water storage tank,clean the spout well for jelly and other thick liquid.Max packing speed is 5000 pouches per hour for 50ml-500ml;we can do the machine according to customer’s production capacity.
Working process of 5000 pouches/h Automatic stand up pouch juice filling capping machine:
(1)Touch screen operation device
(2)Fully automatic pouch supply
(3)Photoelectric detection and tracking.No bag no filling device.
(4)Automatic quantitive filling.
(5)Fully automatic bag cleaning
(6)Fully automatic cap supply
(7)Fully automatic capping
(8)Fully automatic bag dropping
(9)Automatic control the liquid level.
(10)Emergency Stop device
(11) Automatic CIP cleaning
(12) Automatic Nitrogen Gas filling function(optional)
Technical parameters of 5000 pouches/h Automatic stand up pouch juice filling capping machine:
Model: | CB-5000 |
Capacity: | 5000 Bags/hour |
Filling Range: | 50-500 ml |
Accuracy | +-1.5% |
Power: | 380V, 50Hz 2.5KW |
Weight: | 950KG |
Dimension:(L*W*H) | 3500*2100*2100 (mm) |
Air pressure | 6Kgf/cm2 |
