1.Model CB-I-125 is Factory semi automatic stand up pouch with spout filling machine.
2.It can packing any liquid such as juice yogurt,water,jelly,soymilk,cooking oil,liquid soap etc.Also used for the semi fluid,example tomato sauce,honey,fruit pasteJam etc.
3.Automatic filling,manual capping.
4.It with single nozzles max packing speed 800bags/hour.
5.International spare parts brand.
6.it is quite suitable for the customer who first time using pouch with spout and with a low production output at beginning.Anyway,input too much labor cost or investment funds is a risk to them.By this method,it not only can help them solve above problem,but also it can help them trying the market feedback about this new packaging.
1) Flowing style(spout pouch filling machine): it is more suitable for the liquid with good flow-ability (such as water)
2) Material tank style(doy pack filling machine): it is more suitable for the product with high density or bad flow-ability (such as oil and ketchup)
1) Flowing style: the customer must assemble by a material tank by themselves,the spout pouch filling equipment will automatic sucked the filling content
2) Material tank style: the doy pack machine has assemble by a material tank,the adjustment valve of machine can adjust the filling speed.
3) Filling speed:600-800 pouches per hour,single filling nozzle is suitable,if the output is higher,more filling nozzle can be chosen.Besides the density of filling contents, the filling speed of machine is also depend on the quantity of feeding mouths, such as below
CB-I-125 Factory semi automatic stand up pouch with spout filling machine is used for any liquid's automatic filling and manual capping,such as juice,milk,jam,yogurt,seasonings,food industry and medicine,daily chemical,pesticide ant other industries.
Full function,rational structure,easy operation and maintenance.It conforms to food hygiene standard.This machine combines machine,electricity and air.Electric and pneumatic components adopt imported devices,reliable performance,long service life,convenient repair,and install leakage protection, protect personal safety.
| Item | CBPE10-2020 |
| model | CB-I-125 |
| power | 40W |
| air | 0.5-0.6MPa |
| filling volume | 1ml-60ml adjustable |
| speed | ≤20 pouches/min |
| filling precision | ≤±0.5% |
| Protection class | IP32 |
| Relative humidity | 10%-85% |
| Operating temperature | 10℃-90℃ |
| Equipment weight | 20Kg |
| Appearance | SUS 304 |
| Dimensions | 800mm×190mm×440mm |
Working process of Factory semi automatic stand up pouch with spout filling machine:
1)Automatic quantitive filling.
(2)Manual capping
(3)Food switch control the filling.
1> More function than other supplier,stable quality & one year warranty.
2> Lower price-not the cheapest but the lowest at the same quality.
3> High customer satisfactory before and after sale.
4> Lifetime maintenance/lifetime service guarantee.
5> Engineer available to service machinery overseas.
6> Provide suitable and perfect packing machine solution with customers.
7> We pay attention to the service customer quality,not customers quantity
1. 13 years manufacture experience,strong R&D department.
2. Exported to more than 1000 customers from more than 50 countries.
3. We promiss machine keep working over 10 years in good working condition.Fewer easy broken parts,easy to change.
4.Intelligent PLC control system,easy operate,more hommization.
5.One year guarantee time,lifelong free service,24 hours online service.
6.High output 2000-4000 bags/hour,save energy & labor.
7.OEM,ODM and customized service.
8.CE ISO BV GMP certificates.
1.Model CB-I-125 is Factory semi automatic stand up pouch with spout filling machine.
2.It can packing any liquid such as juice yogurt,water,jelly,soymilk,cooking oil,liquid soap etc.Also used for the semi fluid,example tomato sauce,honey,fruit pasteJam etc.
3.Automatic filling,manual capping.
4.It with single nozzles max packing speed 800bags/hour.
5.International spare parts brand.
6.it is quite suitable for the customer who first time using pouch with spout and with a low production output at beginning.Anyway,input too much labor cost or investment funds is a risk to them.By this method,it not only can help them solve above problem,but also it can help them trying the market feedback about this new packaging.
1) Flowing style(spout pouch filling machine): it is more suitable for the liquid with good flow-ability (such as water)
2) Material tank style(doy pack filling machine): it is more suitable for the product with high density or bad flow-ability (such as oil and ketchup)
1) Flowing style: the customer must assemble by a material tank by themselves,the spout pouch filling equipment will automatic sucked the filling content
2) Material tank style: the doy pack machine has assemble by a material tank,the adjustment valve of machine can adjust the filling speed.
3) Filling speed:600-800 pouches per hour,single filling nozzle is suitable,if the output is higher,more filling nozzle can be chosen.Besides the density of filling contents, the filling speed of machine is also depend on the quantity of feeding mouths, such as below
CB-I-125 Factory semi automatic stand up pouch with spout filling machine is used for any liquid's automatic filling and manual capping,such as juice,milk,jam,yogurt,seasonings,food industry and medicine,daily chemical,pesticide ant other industries.
Full function,rational structure,easy operation and maintenance.It conforms to food hygiene standard.This machine combines machine,electricity and air.Electric and pneumatic components adopt imported devices,reliable performance,long service life,convenient repair,and install leakage protection, protect personal safety.
| Item | CBPE10-2020 |
| model | CB-I-125 |
| power | 40W |
| air | 0.5-0.6MPa |
| filling volume | 1ml-60ml adjustable |
| speed | ≤20 pouches/min |
| filling precision | ≤±0.5% |
| Protection class | IP32 |
| Relative humidity | 10%-85% |
| Operating temperature | 10℃-90℃ |
| Equipment weight | 20Kg |
| Appearance | SUS 304 |
| Dimensions | 800mm×190mm×440mm |
Working process of Factory semi automatic stand up pouch with spout filling machine:
1)Automatic quantitive filling.
(2)Manual capping
(3)Food switch control the filling.
1> More function than other supplier,stable quality & one year warranty.
2> Lower price-not the cheapest but the lowest at the same quality.
3> High customer satisfactory before and after sale.
4> Lifetime maintenance/lifetime service guarantee.
5> Engineer available to service machinery overseas.
6> Provide suitable and perfect packing machine solution with customers.
7> We pay attention to the service customer quality,not customers quantity
1. 13 years manufacture experience,strong R&D department.
2. Exported to more than 1000 customers from more than 50 countries.
3. We promiss machine keep working over 10 years in good working condition.Fewer easy broken parts,easy to change.
4.Intelligent PLC control system,easy operate,more hommization.
5.One year guarantee time,lifelong free service,24 hours online service.
6.High output 2000-4000 bags/hour,save energy & labor.
7.OEM,ODM and customized service.
8.CE ISO BV GMP certificates.
